Item |
SLM580 |
|
Load weight |
500 Kg |
|
Bucket capacity |
0.3 m3 |
|
Max lifting power |
1258Kg |
|
speed |
0-8Km/h |
|
Operating weight |
1775kg |
|
Max working height |
2420 mm |
|
Max pin height |
2099 mm |
|
Max dump height |
1617 mm |
|
The highest point discharge distance |
615 mm |
|
Bucket swing angle |
79° |
|
Bucket unloading angle |
36° |
|
Opening-closing angle |
43° |
|
Angle of departure |
30° |
|
Total height |
1607 mm |
|
The height from the ground |
300 mm |
|
Wheelbase |
1065 mm |
|
No bucket length |
2200 mm |
|
Total width 1033 |
1033 mm |
|
Bucket width |
1140 mm |
|
Total length（with bucket） |
2752 mm |
|
Turning radius (R) |
2198 mm |
|
Engine |
D1105-EF02 |
|
Rated power |
18.2KW/25HP |
|
Rotating speed（rpm） |
3000 |
|
Noise（Db） |
≤95 |
|
Hydraulic pressure（Mpa） |
20 |
|
Raise time |
3.89 s |
|
Dump time |
1.6 s |
|
Lower time |
3.35 s |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international trade sales shall prevail;
