Model |
LT968G |
|
Rated power |
178KW/2200r/min |
|
Overall dimensions |
8700mmX3100mmX3670mm |
|
Operating weight |
19800KG |
|
Rated loading capacity |
6000KG |
|
Bucket capacity |
4m³ |
|
Bucket width |
3160mm |
|
Wheelbase |
3100mm |
|
Dumping height |
3600mm |
|
Dumping reach |
1300mm |
|
Turning angle |
35°±1° |
|
Max. Climbing Gradient |
28° |
|
Turning radius |
7134mm |
|
Max. breakout force |
175kN |
|
Max. torque |
1000N.m |
|
Lifting time |
≤6.5s |
|
Hydraulic cylinder time |
≤10.5s |
|
Specification of tire |
26.5-25 |
|
Travel speed |
|
|
Forward gear Ⅰ |
11.5km/h |
|
Forward gearⅡ |
38km/h |
|
Reverse gear Ⅰ |
16km/h |
With technological innovation our product configuration and parameters will continue to change without notice;
if there is any doubt the specific confirmation of our international tra
