| Maximum lift capacity | 最大举升重量 | 3000kg |
| Lift capacity to full height | 最大举升高度的举升重量 | 2500kg |
| Lift capacity at full reach | 最大前伸长度下的举升重量 | 1100kg |
| Lift height | 最大举升高度 | 7000mm |
| Reach at maximum lift height | 最大举升高度下的卸载距离 | 450mm |
| Maximum forward reach | 最大前伸长度 | 3600mm |
| Weight unload | 整机重量 | 7000kg |
| Tyre | 轮胎 | 16/70-20 |
| Outside turn radius(over tyre) | 转弯半径（轮胎外沿） | 4250mm |
| Carriage roll back angle(degrees) | 转向角度 | 42.6 |
| Carriage dump angle(degrees) | 卸料角度 | 37.5 |
| Overall height | 高度 | 2400mm |
| Overall width(over tyres) | 宽度 | 2200mm |
| Inside width of cab | 驾驶室宽度 | 800mm |
| Front track | 轮距 | 1750mm |
| Wheelbase | 轴距 | 2850mm |
| Overall length to front tyres | 到前轮胎的长度 | 4200mm |
| Overall length to front carriage | 到设备前端的长度 | 4650mm |
| Ground clearance | 离地间隙 | 350mm |
| Engine brand | 发动机品牌 | YUNNEI CUMMINS ADD2500USD |
| Engine rate power | 发动机额定功率 | 76KW |
| Pallet fork length | 叉齿长度 | 1220mm |
| Warranty time | 质保时间 | 1 year or 1200 working hours |
| Delivery time | 交货期 | Within 45 working days after receipt of deposit |
