| 1. Parameters : | ||||
| Overall Performance/Models整体型号 | Unit | LT916 | ||
| General Machine Performance 机器整体参数 | Operating weight | 整机重量 | kg | 2100 |
| Length (L) | 长 | mm | 4500 | |
| Width (W) | 宽 | mm | 1530 | |
| Height (H) | 高 | mm | 2450 | |
| Wheel base | 轴距 | mm | 1820 | |
| Wheel track | 轮距 | mm | 1300 | |
| Turning radius | 转弯半径 | mm | 4900/4450 | |
| Total cycle time | 三项和 | s | 9 | |
| Tire size | 轮胎尺寸 | size | 7.50-16 | |
| Max.travelling speed | 最大行驶速度 | km/h | 35 | |
| Bucket Performance 铲斗参数 | Loading weight | 装载量 | kg | 600 |
| Standard bucket capacity | 标准铲斗斗容 | m3 | 0.35 | |
| Possible Bucket capacity | 铲斗斗容范围 | m3 | 0.35-0.7 | |
| Bucket width | 铲斗宽度 | mm | 1530 | |
| Dumping height | 卸高 | mm | 2300 | |
| Dumping reach | 卸距 | mm | 760 | |
| Max. lifting height | 最大举升高度 | mm | 3400 | |
| Transmission Performance 变速箱参数 | Transmission type | 变速箱类型 | type | automatic |
| Control type | 控制方式 | type | mechanical | |
| Engine Performance 发动机参数 | Brand | 品牌 | name | Yunnei |
| Model | 型号 | name | YN25GB | |
| Power | 功率 | kw/ rpm | 37 | |
| Rotate speed | 转速 | rpm | 2400 | |
| Number of cylinders | 缸数 | Unit | 4 | |
| 1. Parameters : | ||||
| Overall Performance/Models整体型号 | Unit | LT916 | ||
| General Machine Performance 机器整体参数 | Operating weight | 整机重量 | kg | 2100 |
| Length (L) | 长 | mm | 4500 | |
| Width (W) | 宽 | mm | 1530 | |
| Height (H) | 高 | mm | 2450 | |
| Wheel base | 轴距 | mm | 1820 | |
| Wheel track | 轮距 | mm | 1300 | |
| Turning radius | 转弯半径 | mm | 4900/4450 | |
| Total cycle time | 三项和 | s | 9 | |
| Tire size | 轮胎尺寸 | size | 7.50-16 | |
| Max.travelling speed | 最大行驶速度 | km/h | 35 | |
| Bucket Performance 铲斗参数 | Loading weight | 装载量 | kg | 600 |
| Standard bucket capacity | 标准铲斗斗容 | m3 | 0.35 | |
| Possible Bucket capacity | 铲斗斗容范围 | m3 | 0.35-0.7 | |
| Bucket width | 铲斗宽度 | mm | 1530 | |
| Dumping height | 卸高 | mm | 2300 | |
| Dumping reach | 卸距 | mm | 760 | |
| Max. lifting height | 最大举升高度 | mm | 3400 | |
| Transmission Performance 变速箱参数 | Transmission type | 变速箱类型 | type | automatic |
| Control type | 控制方式 | type | mechanical | |
| Engine Performance 发动机参数 | Brand | 品牌 | name | Yunnei |
| Model | 型号 | name | YN25GB | |
| Power | 功率 | kw/ rpm | 37 | |
| Rotate speed | 转速 | rpm | 2400 | |
| Number of cylinders | 缸数 | Unit | 4 | |
